KOMODO MINI V2

Name: KOMODO MINI V2
Brand: BatteryEVO
SKU: EVO-KMDO-03080-24
Price: 4400.00 USD
Availability: InStock

SKU: EVO-KMDO-03080-24

$4,400.00 USD

📄 Download Spec Sheet

Product Description:

The Komodo Mini V2 is a compact, track-driven power system designed for field mobility and off-grid use. Equipped with a 3000W inverter and an 8kWh NMC battery, it provides reliable 110V AC power wherever you need it — all while being remotely maneuverable.

Key Features

8kWh NMC Battery with 150A BMS for efficient energy delivery
3000W Inverter (110V) with 6× GFCI AC outlets
4× USB-A Ports for charging small electronics
Remote-Controlled Dual-Track Mobility for uneven terrain
Light-duty Dragging Capability for field tools or cables
Compact Build (189 lbs) for easy transport

Note: The unit has limited towing capacity and is best suited for short-distance repositioning.

BatteryEVO provides a 10-year warranty with lifetime technical support, covering free repair or replacement of defective battery cells and ensuring reliable long-term performance.

BatteryEVO’s Return and Exchange Policy requires customers to provide photos and proper packaging before returns, covers accessories with a 30-day replacement period, applies a 20% restocking fee for non-defective returns, and may involve additional fees for lithium battery shipments due to regulatory requirements.

Related items

Product FAQ's

The built-in 3000W inverter (110V only) supports most household electronics and small appliances, such as laptops, lights, TVs, fans, small power tools, and even mini fridges. For best performance, ensure your total load stays within the 3000W continuous limit.

With 8kWh of usable battery capacity, runtime depends on your load:

-Light loads (~300W): Up to 24 hours;
-Moderate loads (~1000W): Around 7–8 hours;
-Heavy loads (~2000–2500W): Approximately 3–4 hours.

Actual results may vary based on usage patterns and environment.

It supports three charging methods:

-AC Charging via wall outlet (through 50A AC port);
-Solar Charging via MPPT controller (90–230VDC, max 80A) — recommended to use 550W high-voltage panels;
-Generator Input — recommend 3kW+ for timely charging.

Always ensure correct voltage and current range when connecting solar panels or generators.

System Voltage	24V
Nominal Voltage	29.3 V
Chemistry	NMC
kWh Capacity	8 kWh
Ah Capacity	260 Ah
Charging Voltage	32 V-33.2 V
Max Charge Voltage	33.2 V
Operating Voltage Range	24 V-33.2 V
Suggested Low Voltage Cutoff	24 V-26.7 V
Cell Configuration	8S1P
Max Continuous Discharge Current	150 A
Max Continuous Power	3000 W
Max Discharge Peak Current	300 A (3 seconds)
Max Charge Current	150 A
Charge Temperature Range	-20°C (-4°F) / 55°C (131°F)
Discharge Temperature Range	-20°C (-4°F) / 55°C (131°F)
Optimal Discharge Temperature Range	15°C (59°F) / 35°C (95°F)
Storage Temperature Range	-5°C (23°F) / 35°C (95°F) (Max 6 Months)
Weight	189 lb
Depth	26 in
Width	21.7 in
Height	19.7 in
